| Dimensions |
Low Profile PCIe Form Factor |
| Disk Drive |
12Gb/s SAS (Serial Attached SCSI) capable |
| |
12Gb/s SAS (Serial Attached SCSI) |
| |
6Gb/s SATA (Serial AT Attachment) |
| SAS Port Link Rate |
12Gb/s per physical link supported; |
| PCIe Link Rate |
PCIe3 x8 |
| Cache Memory |
DDR3-1866MHz, 72-bit wide bus at 14.9GB/s (4GB cache module) |
| Physical Drives Supported |
Up to 8 drives without 12G SAS Expander card; up to 48 drives with 2 SAS Expander card (ML350 Gen9) |
| Logical Drives Supported |
Up to 64 logical drives |
| Memory Addressing |
64-bit, supporting servers with memory space greater than 4 GiB (4.4GB) |
| RAID Support |
RAID 6, 60 (Advanced Data Guarding) |
| |
RAID 5, 50 (Distributed Data Guarding) |
| |
RAID 1, 10 (Drive Mirroring) |
| |
RAID 1 ADM, 10 ADM (Advanced Data Mirroring) |
| |
RAID 0 (Striping) |
| Upgradeable Firmware |
Upgradeable firmware with recovery ROM feature |
